Australian Standard Hot Sale Aluminum Casement Window Energy-saving Glass Soundproof Homes Window
Product About 86 tilt and turn window
The profile adopts high-precision industrial aluminum profile, and the total thickness of its frame is 86mm,The thermal insulation strip adopts25.3 mm nylon thermal insulation strip.The corner connection adopts the mechanical impact angle method and stainless plate to guide double-component sealant injection,The window screen has an integrated double inner opening function, and the screen window is detachable,Three glass hollow 5+12A+5+12A+5 (39mm±0.5)
Related Parameters
|
Open Style |
Sliding |
PROFILE THICKNESS |
1.44mm |
|
SASH VİSİBLE WIDTH |
47mm |
FRAME VİSİBLE WIDTH |
30mm |
|
GLASS CONFIGURATION |
5+14A+5+14A+5 Three glass hollow |
INSULATION PERFORMANCE CLASSİFİCATION |
7Grade 2.5> K>2.0 |
|
SOUND İNSULATİON PERFORMANCE CLASSİFİCATİON |
4Grade 30≤Rw+Ctr <35 |
WATER TIGHTNESS CLASSİFİCATION |
5Grade 500≤p<700 |
|
AIR TIGHTNESS CLASSİFİCATION |
6Grade 1.52p1 p1>1.0,4.>P2 P2>3.0 |
WIND PRESSURE PERFORMANCE CLASSİFİCATION |
8Grade 4.5 |
THE SURFACE COATING OF PROFILES IS ELECTROSTATIC SPRAYING PROCESS
HARDWARE RECOMMEND HOPO (EXPOSED\HIDDEN)
The middle frame connection adopts screw connection, water-stop sheet glue injection, and glue sealing at the joints
The internal lap joint and external flush structure design are adopted, and the overall structure is firm andBeautiful and generous, square crimping makes the whole window beautiful and angular clear
The product adopts the structural design of open drainage buckle cover, which is not only It can make the rainwater entering the window drain out of the room smoothly and quickly to ensureThe watertight performance of the whole window can effectively prevent mosquitoes from entering the room
